They can realize automatic control. They can finish all kinds of turning inwhirling surfaces automaticiy such as the inner circle and excircle of hardwares, end surface kerbens, any conical surfaces and spherical surfaces. They also can complete many manufacturing procedure, including all kinds of metric syetem and British measurement columns and taper screw threads etc. At the same time, they have the self-contained function of S. T. M and can send out and receive many kinds of informations, control the process of automatic machining.
Model
| CJK630
| CK800
|
Max. swing over bed
| 630Cmm
| 800mm
|
Max. swing over tool-post
| 350mm
| 520mm
|
Max. length of the work - piece
| 1500mm
| 1500mm 3000mm
|
Range of the speed
| 7.5 -1000r/min
| 7.5 - 1000r/min
|
Spinde bore
| φ 100mm
| φ 100mm
|
Table of bore in spinde
| 1; 20
| 1; 20
|
Rapid traverse rate
| X; 3800mm/min Z: 7600mm/min
| X; 3800mm/min Z: 7600mm/min
|
Min. feed unit
| X: 0.0005mm Z: 0.001mm
| X: 0.0005mm Z: 0.001mm
|
Feed motor
| Servo motor
| Servo motor
|
Main motor power
| 11kw
| 11kw
|
CNC system
| GSK980TD GSK980TD
(Also change the system according to the user’ s option)
|
Tool post
| 4 position
| 4 position
|
Net weight
| 4.8T
| 6.2T
|
Overall dimensions(Lengh× Width× Height)
| 3690× 1650× 1770mm
| 3690× 1750× 1780mm
|
