CNC Hydraulic Sheet Metal Manual Rolling Machine

Customization:	Available
Condition:	New
Certification:	ISO 9001:2008, CE, ISO 9001:2000

Quantity:



Inquire Add to Basket

Product Description

Basic Info.

Model NO.

WC67Y 63T3200

Automation

Automatic

Type

Press Brake

Pressure

63t

Width

3200mm

Process Material

Metal Plate

Tool

Customed

Application

Machinery & Hardware

Type for Cutting Machine

CNC Cutting Machine

Type for Fold-bending Machine

Hydraulic Fold-bend Machine

Type for Pipe and Tube Bending Machine

Digital Pipe Bender

Transport Package

Steel Tray

Specification

International Standard

Trademark

Aluke

Origin

China

HS Code

846229

Production Capacity

130 Sets/Month

Product Description

CNC hydraulic sheet metal manual Rolling Machine

1.Functions

This machine is high-efficiency and high-precision in bending sheet metal. Using different kinds of upper and lower dies can bend all kinds of work pieces. One slider travel makes a sheet bending and the complicated shape work piece may be achieved through bending many times. When fitted with relevant equipments, it can be used to punch holes.

2.Overall structure

2.1 Using UG (finite element) analysis, through computer aid design, with nice appearance.

2.2 The machine structure is welded with steel plate, with sufficient strength and rigidity. The hydraulic drive prevents the machine from serious overload operation accidents caused by the change of sheet thickness or bad choice of lower die cavity. Additionally, this machine is also featured by the steadiness of work, convenience of operation, and reliable safety.

3.Parts of supply list

Tool clamping and Press Brake Die

Backgauge and Ball screw(Taiwan HIWIN)

Main electric elements(Siemens)

NO.	Item	Parameter value	Unit	Remark
1	Nominal force	630	KN
2	Bending width	3200	mm
3	Slider travel	100	mm
4	Max opening height	320	mm
5	Distance between vertical poles	2560	mm
6	Depth of throat	300	mm
7	Travel times	8	T/M
8	Internal gear pump	NT4-40F
9	Max force of system	22	22
10	Motor power	7.5	KW
