WC67Y 63T Torsion Bar Heavy Duty Rolling Machine
Functions:
This high-efficiency and high-precision rolling machine is designed for bending sheet metal. It can bend various workpieces using different upper and lower dies. With a single slider travel, it can bend sheets and create complex shapes through multiple bends. Equipped with additional tools, it can also be used for punching holes.
Overall Structure:
- Utilizes UG (finite element) analysis and computer-aided design for a visually appealing appearance.
- Welded steel plate structure ensures strength and rigidity.
- Hydraulic drive system prevents overload accidents due to sheet thickness changes or improper die selection.
- Features stable operation, easy usability, and reliable safety measures.
Parts Supply List:
- Tool clamping and Press Brake Die
- Backgauge and Ball screw (Taiwan HIWIN)
- Main electric elements (Siemens)
Manufactured by Shanghai Aluke Equipment Co., Ltd.
| No. | Name | 63T4000 |
| Value | Unit | Notes |
| 1 | Nominal pressure | 630 | KN | |
| 2 | Length of workbench | 4000 | mm | |
| 3 | Width of workbench | 150 | mm | |
| 4 | Poles distance | 3100 | mm | |
| 5 | Throat depth | 250 | mm | |
| 6 | Max stroke | 120 | mm | |
| 7 | Max open | 380 | mm | |
| 8 | Back gauge stroke | 410 | mm | |
| 9 | Gear pump | model | NT2G-10F | | |
| 10 | flow | 10 | L/min | |
| 11 | pressure | 31.5 | MPa | |
| 12 | Slider speed | Up | 60 | mm/s | |
| 13 | Down | 60 | mm/s | |
| 14 | Inflating | 10 | mm/s | |
| 15 | Thickness of workbench | 50 | mm | |
| 16 | Main power | 5.5 | KW | |
| 17 | Power | 380V/50Hz/3Phase(According to customer requirements changes) |
