We have an excellent technical team, our products in quality and quantity will make you satisfied, welcome to buy
 |
| Customization: | Available |
|---|---|
| Type: | Hydraulic Machine |
| Forging Forming Method: | Mold Forging |
| Quantity: | |
|---|---|
| No. | Name | Value | Unit | Notes | |
| 1 | Nominal pressure | 1000 | KN | ||
| 2 | Length of workbench | 3200 | mm | ||
| 3 | Width of workbench | 180 | mm | ||
| 4 | Poles distance | 2600 | mm | ||
| 5 | Throat depth | 320 | mm | ||
| 6 | Max stroke | 120 | mm | ||
| 7 | Max open | 430 | mm | ||
| 8 | Back gauge stroke | 600 | mm | ||
| 9 | Gear pump | model | NT3G-25F | ||
| 10 | flow | 25 | L/min | ||
| 11 | pressure | 31.5 | MPa | ||
| 12 | Thickness of workbench | 70 | mm | ||
| 13 | Main power | 7.5 | KW | ||
| 14 | Power | 380V.50HZ.3PHASE(According to customer requirements changes) | |||
| No | Item | Quantity | Unit | Place of origin |
| 1 | Hydraulic system | 1 | set | Rexroth |
| 2 | Oil pump | 1 | set | Made in shanghai |
| 3 | Hydraulic valve | 1 | set | Rexroth |
| 4 | Sealing rings | 1 | set | Taiwan DZ |
| 5 | Main electrical system | 1 | set | French Schneider Electric or SIEMENS |
| 6 | Ball screw | 2 | pieces | Taiwan HIWIN |
| 7 | Linear guide | 2 | pieces | Taiwan HIWIN |
| 8 | Pipe joint | 1 | set | German EMB |
| 9 | Gear pump | 1 | piece | Taifeng,Made in china |
| 10 | Motor | 1 | piece | SIEMENS |
| No. | Name | Value | Unit | Notes | |
| 1 | Nominal pressure | 1000 | KN | ||
| 2 | Length of workbench | 3200 | mm | ||
| 3 | Width of workbench | 180 | mm | ||
| 4 | Poles distance | 2600 | mm | ||
| 5 | Throat depth | 320 | mm | ||
| 6 | Max stroke | 120 | mm | ||
| 7 | Max open | 430 | mm | ||
| 8 | Back gauge stroke | 600 | mm | ||
| 9 | Gear pump | model | NT3G-25F | ||
| 10 | flow | 25 | L/min | ||
| 11 | pressure | 31.5 | MPa | ||
| 12 | Thickness of workbench | 70 | mm | ||
| 13 | Main power | 7.5 | KW | ||
| 14 | Power | 380V.50HZ.3PHASE(According to customer requirements changes) | |||
| No | Item | Quantity | Unit | Place of origin |
| 1 | Hydraulic system | 1 | set | Rexroth |
| 2 | Oil pump | 1 | set | Made in shanghai |
| 3 | Hydraulic valve | 1 | set | Rexroth |
| 4 | Sealing rings | 1 | set | Taiwan DZ |
| 5 | Main electrical system | 1 | set | French Schneider Electric or SIEMENS |
| 6 | Ball screw | 2 | pieces | Taiwan HIWIN |
| 7 | Linear guide | 2 | pieces | Taiwan HIWIN |
| 8 | Pipe joint | 1 | set | German EMB |
| 9 | Gear pump | 1 | piece | Taifeng,Made in china |
| 10 | Motor | 1 | piece | SIEMENS |
