We have an excellent technical team, our products in quality and quantity will make you satisfied, welcome to buy
 |
| Customization: | Available |
|---|---|
| Certification: | ISO 9001:2008, CE, ISO 9001:2000 |
| Automation: | Automatic |
| Quantity: | |
|---|---|
| Number | Name | Value | Unit | Notes |
| 1 | Nominal pressure | 630 | KN | |
| 2 | Length of workbench | 1600 | mm | |
| 3 | Width of workbench | 150 | mm | |
| 4 | Poles distance | 1200 | mm | |
| 5 | Throat depth | 320 | mm | |
| 6 | Max stroke | 100 | mm | |
| 7 | Max open | 360 | mm | |
| 8 | Back gauge stroke | 410 | mm | |
| 9 | Gear pump | model | NT2G-10F | |
| 10 | flow | 10 | L/min | |
| 11 | pressure | 31.5 | MPa | |
| 12 | Thickness of workbench | 50 | mm | |
| 13 | Main power | 5.5 | KW | |
| 14 | Slider speed | Up | 60 | Mm/s |
| Down | 60 | Mm/s | ||
| Inflating | 10 | Mm/s | ||
| 14 | Dimension | 1600X1120X1900MM | L*W*H | |
| 15 | Gross weight | 2400Kg |
| Number | Name | Value | Unit | Notes |
| 1 | Nominal pressure | 630 | KN | |
| 2 | Length of workbench | 1600 | mm | |
| 3 | Width of workbench | 150 | mm | |
| 4 | Poles distance | 1200 | mm | |
| 5 | Throat depth | 320 | mm | |
| 6 | Max stroke | 100 | mm | |
| 7 | Max open | 360 | mm | |
| 8 | Back gauge stroke | 410 | mm | |
| 9 | Gear pump | model | NT2G-10F | |
| 10 | flow | 10 | L/min | |
| 11 | pressure | 31.5 | MPa | |
| 12 | Thickness of workbench | 50 | mm | |
| 13 | Main power | 5.5 | KW | |
| 14 | Slider speed | Up | 60 | Mm/s |
| Down | 60 | Mm/s | ||
| Inflating | 10 | Mm/s | ||
| 14 | Dimension | 1600X1120X1900MM | L*W*H | |
| 15 | Gross weight | 2400Kg |
