We have an excellent technical team, our products in quality and quantity will make you satisfied, welcome to buy
 |
| Customization: | Available |
|---|---|
| Type: | Hydraulic Machine |
| Forging Forming Method: | Mold Forging |
| Quantity: | |
|---|---|
| NO. | Item | Parameter value | Unit | Remark |
1 | Nominal force | 800 | KN | |
2 | Bending width | 4000 | mm | |
3 | Slider travel | 120 | mm | |
4 | Max opening height | 385 | mm | |
5 | Distance between vertical poles | 2955 | mm | |
6 | Depth of throat | 300 | mm | |
7 | Travel times | 8 | T/M | |
8 | Internal Gear Pump | NT Series | ||
| 9 | Max force of system | 22 | Mpa | |
| 10 | Motor power | 7.5 | Kw | |
| No | Item | Quantity | Unit | Place of origin |
| 1 | Hydraulic system | 1 | set | Rexroth |
| 2 | Oil pump | 1 | set | Made in shanghai |
| 3 | Hydraulic valve | 1 | set | Rexroth |
| 4 | Sealing rings | 1 | set | Taiwan DZ |
| 5 | Main electrical system | 1 | set | French Schneider Electric or SIEMENS |
| 6 | Ball screw | 2 | pieces | Taiwan HIWIN |
| 7 | Linear guide | 2 | pieces | Taiwan HIWIN |
| 8 | Pipe joint | 1 | set | German EMB |
| 9 | Gear pump | 1 | piece | Taifeng,Made in china |
| 10 | Motor | 1 | piece | SIEMENS |
